WL-6

Consult

Features Technical Indicators Overall Dimension

(1) High conductivity: Excellent conductivity can be achieved with a relatively low loading. It has high conductivity and oil absorption value. Good thermal conductivity.
(2) High dispersibility: Easy to process and mix, achieving a balance of electrical properties/mechanical properties of the material, and the final product is smooth and smooth. Light weight, small specific gravity, large specific surface area, strong adsorption, stable chemical properties, good surface activity, and high conductivity.
(3) High purity: The unique production process ensures that the purity, ash content, sulfur and metal content of the conductive material are low, which can achieve excellent conductivity, high purity, low ash content and low volatile matter.

No.	WL-6 (S-P) Test items		Unit GB
1	Particle size D50	nm 40±5	Enterprise Standards
2	Specific surface area	m/g 57-67	42
3	Moisture	% ≤0.30	60
4	Ash	% ≤0.5	≤0.10
5	Tap density	g/cm3 ≥0.13	≤0.7
6	DBP adsorption	MI/100g 285-240	≥0.15
7	Impurity content	Fe ppm 300	460-490
		S ppm 30	≤50
		Mo ppm 10	≤0.5
		C1 ppc 10	≤0.5
8	Electric,resistanc enc	Ω·m 2.5-3.0	<2.0
9	Loss by drying	%3	<0.8
10	PH Value	7.5-9	8.0-8.5
11	Microscopic morphology		Pure black powder and granules
12	Appearance		No knots, no debris
13	Volatile Matter	%0.1-0.5	≤0.02
14	iodineadsorpion	mg/g	490-550
15	Nitroge radsorption	m/g	>480
16	Sulfurcontent	%	<0.5
